HTBasic 10 程式語言軟體
- HTBasic 10 程式語言軟體
-
類別程式開發軟體
-
介紹HTBasic的窗口式編輯器，具有書籤、用戶自定義字體、彩色關鍵字和語法錯誤識別等功能，即使是最大的源代碼，程序員也能輕鬆瀏覽和編輯。切換關閉行號消除了低效的編程限制，同時又不影響編程的方便性。
-
價格
HTBasic 10 Programming Language Software
• Built-in syntax for controlling GPIB, GPIO, and data acquisition
cards from companies like National Instruments, Agilent, TAMS,
Keysight, Keithley,Ines, IOtech, Data Translation…
• A Visual no-coding Screen Builder (compatible with BasicPlus)
that includes widgets for: data presentation–like bars, bitmaps,
clocks, meters,and strip charts; Menu Creation–like menu
buttons, cascade menus, and pull-down menus; Data Input–like
keypads, pushbuttons, radio buttons,scrollbars, sliders and tog
gle buttons; and Dialog Statements–for displaying errors, file
names, lists, questions, and warnings.
• Integrated debugger speeds program development. Set
conditional and global breakpoints, step into, step out of, or
step over subprograms.
Includes six exclusive debugging windows for Watch variables, Line Breakpoints, Global Breakpoints, Trace, Call Stack and a
debug Code Window.
• DLL Toolkit allows HTBasic to call Dynamic Link Libraries (DLL’s)
written in other languages like C/C++.
• Supports COMPLEX numbers, LONG integers, and STATIC varia bles types together with matrix math, and structured program
ming.
• Built-in HELP, plus on-line documentation.
• Still backwards compatible with legacy HP workstation
BASlC (RMB)
including LIF and the TRANSFER function for GPIB, serial and
file,while also supporting modern Windows standards on the
PC. LXI/GPIB INSTRUMENT CONTROL 24 HTBasic is backwards
compatible with legacy Hewlett-Packard RMB workstations incl
uding connection to instruments over IEEE-488 (GPIB/HPIB) usi
ng 3rd party interface cards. Plus, HTBasic also supports moder
n standards like LXI (Lan Extensions for Instruments) over ether
net. HTBasic is vendor agnostic and connects to any make of in
strument. HTBasic also supports Data Acquisition (DAQ) cards
from vendors like National Instruments and Ines.
DATA ANALYSIS
Supported data types include Complex numbers, Long integers, and Static variables. Along with built-in matrix math operations and multi-megabyte array capabilities, HTBasic can handle whatever your data reduction and analysis requirements are.
Because HTBasic combines acquisition, analysis and presentation in the same easy-to-use programming language combined with a visual widget based graphical screen builder, it can handle your data from start to finish.
HTBasic includes an Advanced Math Library with highly optimized precompiled functions for things like signal processing, FFT, and curve fitting. Plus HTBasic includes a Numeric Compiler for other user defined math intensive HTBasic subroutines that provides significant performance increases when needed.
VISUAL SCREEN BUILDER
Create custom operator-interface and data presentation graphics screens from dozens of built-in widgets and dialogs with the Screen Builder App (aka BasicPlus). Screen Builder includes widgets
like XY graphs, strip charts, meters, and bar displays.
You can also create Dialog Boxes that display questions, warnings, error messages and other critical information quickly and easily. For example, a single strip chart can be configured a myriad of different ways as needed with more than a dozen core attributes and dozens of specific attributes.
The Screen Builder application also includes widgets for keypads, pushbuttons, scrollbars, toggle buttons, and more so you can customize screens with operator-interface and data presentation without coding.
WINDOWS INTERFACE
HTBasic implements a classic Windows user interface with toolbar, status bar, pulldown menus, scroll bars and dialog boxes. HTBasic also provides access to external features of the Windows environment through user created DLLs that can be written in C/C++ and called through an integrated DLL loader.
系統需求
需要Windows 10，Windows Vista或Windows 7
CPU:
400 MHz或更高的處理器.
RAM:
需要128 MB RAM
HD:
需要300 MB的可用硬盤空間
HTBasic 10 程式語言軟體
• 內置語法，用於控制來自National Instruments，Agilent，TAMS，
Keysight，Keithley，Ines，IOtech，Data Translation等公司的
GPIB，GPIO和數據採集卡…
• 可視化的無編碼屏幕生成器（與BasicPlus兼容），包括用於以下各項的
小部件：數據表示–如條形圖，位圖，時鐘，儀表和帶狀圖；菜單創建
-類似於菜單按鈕，級聯菜單和下拉菜單；數據輸入-如鍵盤，按鈕，
單選按鈕，滾動條，滑塊和切換按鈕；和對話框語句-用於顯示錯誤，
文件名，列表，問題和警告。
• 集成調試器可加快程序開發速度。設置條件和全局斷點，進入，
退出或遍歷子程序。包括六個專用的監視窗口，分別用於監視變量，
行斷點，全局斷點，跟踪，調用堆棧和調試代碼窗口。
• DLL Toolkit允許HTBasic調用以其他語言（如C / C ++）編寫的動態
鏈接庫（DLL）。
• 支持COMPLEX數字，LONG整數和STATIC變量類型，以及矩陣數學和
結構化編程。
• 內置幫助以及在線文檔。
• 仍與舊版HP工作站BASlC（RMB）向後兼容，包括LIF和GPIB，
串行和文件傳輸功能，同時還支持PC上的現代Windows標準。
LXI / GPIB儀器控制
HTBasic向後兼容舊版的HP RMB工作站，包括使用第三方接口卡通過IEEE-488（GPIB / HPIB）連接到儀器。此外，HTBasic還支持諸如以太網上的LXI（儀器的局域網擴展）之類的現代標準。HTBasic與供應商無關，並且可以連接到任何品牌的儀器。HTBasic還支持來自National Instruments和Ines等供應商的數據採集（DAQ）卡。
數據分析
支持的數據類型包括複數，長整數和靜態變量。借助內置的矩陣數學運算和數兆字節的陣列功能，HTBasic可以滿足您對數據縮減和分析的任何要求。
因為HTBasic將易用的編程語言與基於可視化窗口小部件的圖形屏幕生成器結合在一起，將採集，分析和演示結合在一起，所以它可以從頭到尾處理您的數據。
HTBasic包括一個高級數學庫，該庫具有針對信號處理，FFT和曲線擬合等高度優化的預編譯功能。Plus HTBasic包括一個用於其他用戶定義的數學密集型HTBasic子例程的數字編譯器，可在需要時顯著提高性能。
可視屏幕生成器
使用Screen Builder應用程序（又名BasicPlus），從數十個內置的小部件和對話框中創建自定義的操作員界面和數據演示圖形屏幕。Screen Builder包括XY圖，帶狀圖，儀表和條形圖之類的小部件。
您還可以創建對話框，以快速，輕鬆地顯示問題，警告，錯誤消息和其他重要信息。例如，一個帶狀圖可以根據需要配置成多種不同的方式，並具有十幾個核心屬性和數十個特定屬性。
Screen Builder應用程序還包括用於小鍵盤，按鈕，滾動條，切換按鈕等的小部件，因此您可以使用操作員界面和數據表示來自定義屏幕，而無需編寫代碼。
WINDOWS界面
HTBasic實現了經典的Windows用戶界面，其中包含工具欄，狀態欄，下拉菜單，滾動條和對話框。HTBasic還通過用戶創建的DLL提供對Windows環境外部功能的訪問，這些DLL可以用C / C ++編寫並通過集成的DLL加載器進行調用。
ModelMaker 程式開發輔助軟體
Model Maker是功能強大，直觀且集成的數字地形建模程序，並且是Model Maker Systems的軟件套件中最先進的程序。這就是為什麼“模型製作器”是全球成千上萬的選擇的原因。
Teechart 2020 圖表物件製作軟體
TeeChart Pro 2020圖表組件庫提供數百種2D和3D圖形樣式，用於數據可視化，56種數學，統計和財務功能，您可以選擇無限數量的軸和30個調色板組件。
