WAsP 12 風電場設計優化與風資源預測評估軟體
- WAsP 12 風電場設計優化與風資源預測評估軟體
-
類別研究分析軟體
-
介紹丹麥Riso國家實驗室研製的WAsP軟體是目前國際認可的進行風電廠發電量計算與風機最優化佈置通用軟體。WAsP軟件套件是風力渦輪機和風電場的風資源評估，選址和能量產出計算的行業標準。WAsP軟件套件用於遍布全球各種地形的站點。對於水平和垂直外推，WAsP使用內置線性IBZ模型，該模型將適用於平坦到中等複雜的地形。如果地形非常複雜且有許多陡坡，WAsP也可以輕鬆訪問外部最先進的CFD模型。
-
價格
WAsP
WAsP has been employed for almost 25 years within wind power meteorology and in the wind power industry – and has become the industry-standard PC-software for wind resource assessment and siting of wind turbines and wind farms. WAsP runs on Windows 2000, XP, Vista and 7, see the hardware and software requirements, and is sold as a single-user licence. Currently, more than 3900 users in over 110 countries and territories have used WAsP for:
• Wind farm production
• Wind farm efficiency
• Micro-siting of wind turbines
• Power production of WTG’s
• Wind resource mapping
• Wind climate estimation
• Wind atlas generation
• Wind data analysis
• Map digitisation & editing
• Power and thrust curve editing
Many more details of what WAsP is all about are given in the WAsP Help system, which you may download from here: WAsP 10 on-line help-file (12,998 KB chm file). Also, you may find usefull information in document Getting Started with WAsP.
The WAsP software package
The WAsP software package consists of five Microsoft installer files: the WAsP program, the WAsP Climate Analyst, the WAsP Map Editor and the WAsP Licencing System. The installation files may be downloaded from the software download page. The WAsP installation program also installs the WAsP Turbine Editor, a complete set of sample data files, several demonstration projects and the Danish Wind Atlas. Documentation is included as on-line help files.
The wind atlas methodology
WAsP is a PC-program for the vertical and horizontal extrapolation of wind climate statistics. It contains several physical models to describe the wind flow over different terrains and close to sheltering obstacles. WAsP is an implementation of the so-called wind atlas methodology, which may be summarised as follows:
Analysis
• time-series of wind speed and direction —> observed wind climate (OWC)
• observed wind climate + site description —> regional wind climate (wind atlas data sets)
Application
• regional wind climate + site description —> predicted wind climate (PWC)
• predicted wind climate + power curve —> annual energy production (AEP) of wind turbine
Wind farm production
• predicted wind climates + WTG characteristics + wind farm layout —> wind farm wake losses
• annual energy productions + wake losses —> net annual energy production of entire wind farm
Click here for more details about the wind atlas methodology, or check the European Wind Atlas for even more detailed descriptions.
WAsP at a glance
This section is under construction...
WAsP general specifications
– System requirements, Installation guide, limitations, licensing, Licencing guide
Working with WAsP
– introduction to workspace, projects, set-up, options
The WAsP models
– flow model, roughness change model, model for sheltering obstacles, model for turbine wakes in wind farms
Reports and scripts
– standard and custom reports, batch mode
Input required by WAsP
– meteorological data, digital maps
Output generated by WAsP
– reports, data files
WAsP風電場設計優化與風資源預測評估軟體
典型的WAsP套件應用：
• 單個風力渦輪機和風力發電場的能量產量計算
• 風電場效率的計算
• 風資源和湍流映射
• 複雜的地形站點
• 海上風電場
• 風電場中各個風力渦輪機的IEC現場評估的風況計算，例如平均風速，風切變，環境湍流，極端風和風流傾角
WAsP包含幾個物理模型來描述不同地形和靠近避難障礙物的風氣候和風流。此外，WAsP包含風電場尾流效應的喚醒模型和平均熱通量條件的穩定性模型。對於水平和垂直外推，WAsP使用內置線性IBZ模型，該模型將適用於平坦到中等複雜的地形。如果地形非常複雜且有許多陡坡，WAsP也可以輕鬆訪問外部最先進的CFD模型。
WAsP用於風資源和能源產量計算的數據來自不同的來源。風 - 氣候輸入可能來自附近氣象桅杆的風測量，或者可能來自中尺度模擬結果。高程描述直接來自航天飛機高程數據或其他數據集，而土地覆蓋描述和附近避難障礙可以從地形圖，數據庫或衛星圖像（谷歌地球）中提取。
WAsP配備了免費軟件實用工具，用於風力數據分析，數字地圖構建和編輯，功率和推力曲線編輯，以及IEC 61400-1現場評估和IEC 61400-12-1功率性能測量。
我們致力於研究誠信，誠實，透明和問責的基本原則，以及DTU重視我們所做的一切的創新思維，信譽和承諾。
丹麥Riso國家實驗室研製的WAsP軟體是目前國際認可的進行風電廠發電量計算與風機最優化佈置通用軟體
